Features
- Pure Sine Wave Inverter
- Built-in MPPT solar charge controller
- Configurable input voltage range for home appliances and personal computers via LCD setting
- Configurable battery charging current based on applications via LCD setting
- Configurable AC/Solar Charger priority via LCD setting
- Compatible to mains voltage or generator power
- Auto restart while AC is recovering
- Overload / Over temperature / short circuit protection
- Smart battery charger design for optimized battery performance
- Cold start function
Specifications
-
Inverter
-
Model: NOVA 3K24
-
Rated Output Power: 3KVA / 3KW
-
Output Voltage Waveform: Pure Sine Wave
-
Output Voltage Regulation: 120 VAC±5%
-
Output Frequency: 60Hz / 50Hz
-
Peak Efficiency: 91%
-
Surge Capacity: 2* rated power for 5s
-
Nominal DC Voltage: 24 VDC
-
Solar Input
-
Max. PV Array Open Circuit Voltage: 250 VDC
-
PV Array MPPT Voltage Range: 90 VDC~230 VDC
-
Max. Input Current: 18A
-
Physical
-
Operation Temperature Range: 14°F ~ 104°F
-
Dimension (D*W*H): 5.6*12.1*18.8in (142.4*307.8*477.6mm)
-
Net Weight: 26.5lb (12kg)
