Features
- True MPPT
- Tracking Efficiency Above 99.5%
- Charge Conversion Efficiency as High as 98%
- 12V/24V DC System Self-Adaptation
- Reverse Discharge Protection
- Targeted for Accuracy
- Overvoltage Protection
- Common Negative Connection
- Charging Data Storage
- External Battery Temp Sensor-Optional
- Conformal Coating for Inside Board
- External Digital Remote Display-Optional
- In-house Design and Manufacture
- Extensive Internal Electronics, In-Circuit Protections, and Safety Protections
- Targeted for Lead Acid Batteries: Gel, AGM, WET, CRYSTAL, CALCIUM Batteries Type Selections
- Targeted for Lithium Batteries: LiFePO4, LTO (Lithium Titanium Oxide), LCO Batteries Type Selections
Specifications
-
System Nominal Voltage: 12/24V Auto
-
Max PV Open Circuit Voltage: 100V DC
-
Charging Technology: MPPT
-
Max PV Charging Current: 60A
-
Max. Recommended PV Input Power: 900 Watt (12V) / 1800 Watt (24V)
-
Charge Conversion Efficiency: ≤98%
-
MPPT Tracking Efficiency: >99.5%
-
Battery Type Preset: Crystal, Gel, AGM, WET, Calcium / LCO, LFP, LTO
-
Housing Case Color: Black / Grey
-
IP Grade: IP43 for Inside PCBA, IP22 for Connection Area
-
Net Weight: 1.90kg / 4.18lb
-
Dimensions (L×W×H): 201×195×85mm (7.9×7.7×3.3in)
