Features
High Power Capacity
- Rated for 37.7A / 600V with UL1015-certified 8AWG tin-plated copper wires
- Tin-plated conductors ensure stable, corrosion-resistant performance
Certified Fire Safety
- MC4 connectors are UL Listed and UL94V0 flame-retardant
- VW-1 rated PVC insulation resists heat up to 221°F (105°C)
Outdoor-Ready Durability
- IP68 waterproof MC4 connectors, pre-installed for secure sealing
- Flame-retardant PP housing operates from -40°F to 185°F
- Reinforced design resists vibration, ideal for mobile and RV use
Quick Flexible Installation
- Small and light (5.9×4.3×1.6 in, 0.34 lb), requires no extra roof support
- Red/black 8AWG wires with polarity markings
- Mount with adhesive, sealant, or screws (not included)
Specifications
General
-
Dimensions (L × W × H): 5.9 × 4.3 × 1.6 in
-
Weight: 0.34 lb
-
Material: Flame-Retardant Polypropylene (PP)
-
Color: Black
-
Operating Temperature: -40°C to 85°C (-40°F to 185°F)
MC4 Connector Details
-
Material: PC Shell
-
Waterproof Rating: IP68
-
Flame Retardant: UL94V0 Certified
-
Certification: UL Listed
Electrical Ratings
-
Maximum Current: 50A
-
Continuous Current: 37.7A
-
Maximum Voltage: 600V (Wire Rating)
-
Wire Standard: UL 1015 8AWG (Red/Black)
-
Wire Conductor: Tin-Plated Copper
-
Wire Insulation: PVC (VW-1 Fire Rated)
-
Wire Temperature Range: -15°C to 105°C (5°F to 221°F)
